How to Change a Tire on Your Sprinter Van

Any off-road adventure comes with its fair share of surprises, and a flat tire is one of the most common—and inconvenient—issues van owners face. Knowing how to change a tire is a fundamental skill, whether you’re hitting the trail or just running errands. Let’s break down the essential tools, safety tips, and steps needed to get your van back on the road, right from the wisdom shared by John from Owl in his detailed van tech series.

Essential Tools for the Job

Before diving into the process, it’s crucial to have the right tools. Here’s a checklist for your van’s tire-changing toolkit:

Air Pressure Gauge: To check tire pressure before and after swapping.
Breaker Bar: Lug bolts are usually tightened between 130 and 150 foot-pounds, so a breaker bar is necessary to loosen them.
Impact Wrench: Useful for speed, though not always powerful enough to break lugs loose.
Socket Set: Both 17mm (for aftermarket wheels) and 19mm (for factory wheels), due to differences in bolt sizes.
Extensions and Adapters: Small extensions help work around tight spaces.
Bottle Jack or Safety Jack: A jack (with or without extensions) is necessary to lift heavy vans, especially off-road.
Jack Base: A sturdy base prevents the jack from sinking into sand or loose ground.
Gloves: For protection during any recovery or repair work.

Safety First

Always ensure these safety precautions before starting:

Put the van in park.
Engage the e-brake.
Block the tires (both front and back, using rocks or proper chocks).
Never go under a vehicle supported only by a jack. Only approach the wheel area with the tire still on or once it’s securely back on.

Step-by-Step Tire Change Guide

1. Loosen Lug Bolts

With the van still on the ground, use the correct socket to loosen the lug bolts. Don’t remove them entirely—just break them loose to make removal easier when the wheel is off the ground. The order doesn’t matter for loosening, but it does for tightening later.

2. Position the Jack

Place your jack (with a solid base if you’re on loose ground) as close to the flat tire as possible, ideally under the axle where it won't slip. If the tire is completely flat, you may need to jack up even higher to fit the fully inflated spare.

3. Lift the Van

Jack the van up until there’s enough clearance beneath the flat tire to swap in the spare. Always make sure the jack is stable and not at risk of tipping or sinking.

4. Remove the Tire

Once the tire is off the ground, remove the lug bolts completely. Don’t toss them in the sand—grit can affect how tightly they secure later on.

5. Install the Spare

If you have an aftermarket tire carrier (such as an Owl ladder tire carrier), accessing your spare is much easier. Otherwise, retrieve the factory spare from under the van. Use your legs (not your back!) to align the new tire and lift it onto the hub.

6. Hand-Tighten Lug Bolts

Start all lug bolts by hand to avoid cross-threading. Once all bolts are threaded, snug them up evenly, but don’t fully torque with the vehicle still jacked up.

7. Lower the Van

Lower the van carefully and remove the jack. Now torque the lug bolts in a star pattern to ensure the wheel sits flush against the hub. Final torque spec for Sprinters is typically around 137 foot-pounds, but getting them "good and tight" is usually sufficient to get you off the trail.

8. Final Checks

Double-check that all lug bolts are tight. Check the spare’s air pressure and adjust as needed. If you’re swapping center caps for aesthetics, do that now. Re-stow tools and secure the flat tire on its carrier, tightening it firmly—especially if the tire is flat, as it may settle more with vibration and time.

9. On the Road Again

Before driving far, retighten the spare after a short distance if it was very flat when first installed. Use a padlock or pin for added safety on the tire carrier to prevent loss or theft.

The Takeaway

Changing a tire on a Sprinter van is straightforward with a solid game plan, the right tools, and careful attention to safety. Don’t underestimate the importance of a sturdy jack base, a breaker bar, and gloves. Most importantly, never head out on the trail without being prepared for this common scenario—self-recovery gear is modestly priced insurance compared to the value of your van and your peace of mind.

Stay safe and ready for whatever the road—or trail—throws your way!
